Freight elevator specification:
| Load(kg) | Speed(m/s) | Door open type | Car door entrance | Entrance | Car Outside size | Shaft inside dimension | Machine room size | |||
| (JJ*HH)mm | (AS*BS)mm | (AH*BH)mm | PP | OH | (W*D*H)mm | |||||
| 1000 | 0.5~1.0 | 2-panel side opening | single entrance | 1200*2100 | 1500*1800 | 2350*2200 | 1400 | 4400 | 2900*3400*3000 | |
| opposite entrances | 1500*1900 | 2350*2200 | ||||||||
| 2000 | 0.5 | 2-panel side opening | single entrance | 1500*2100 | 2000*2300 | 2900*2600 | 1500 | 4500 | 2900*3500*3000 | |
| opposite entrances | 2000*2400 | 2900*2700 | ||||||||
| 4-panel central parting | single entrance | 2000*2300 | 3000*2600 | 3050*3500*3000 | ||||||
| opposite entrances | 2000*2400 | 3000*2700 | ||||||||
| 3000 | 0.5 | 2-panel side opening | single entrance | 1800*2200 | 2400*2600 | 3350*3000 | 1500 | 4500 | 3350*4000*3000 | |
| opposite entrances | 2400*2700 | 3350*3000 | ||||||||
| 4-panel central parting | single entrance | 2400*2600 | 3450*3000 | 3450*4000*3000 | ||||||
| opposite entrances | 2400*2700 | 3450*3000 | ||||||||
| 4000 | 0.25~0.5 | 4-panel central parting | single entrance | 2000*2200 | 2600*3100 | 3800*3500 | 1600 | 4600 | 3800*4500*3000 | |
| opposite entrances | 2600*3200 | 3800*3500 | ||||||||
| 5000 | 0.25~0.5 | 4-panel central parting | single entrance | 2400*2400 | 3000*3200 | 4200*3500 | 1600 | 4800 | 3800*4800*3000 | |
| opposite entrances | 3000*3300 | 4200*3600 | ||||||||
| 10000 | 0.25 | 4-panel central parting | single entrance | 3200*2800 | 3300*5450 | 5300*6050 | 1700 | 5500 | 5300*6000*4000 | |
| opposite entrances | 3300*5500 | 5300*5850 | 5300*5850*4000 | |||||||
MRL freight elevator specification:
Load(kg)
Speed(m/s)
Car net size（CW*CD*CH)
Door opening (OP*OH)
Shaft dimension (HW*HD)
Pit depth(S)
Overhead height(K)
1000
0.5
1400*1600*2200
1200*2100
2600*2400
1500
4500
1600
0.5
1800*2100*2200
1400*2100
2900*2500
1600
4500
2000
0.5
2000*2300*2200
1500*2100
3350*2650
1600
4600
3000
0.5
2400*2600*2200
1800*2100
3850*3000
1800
5000
Function:
Note: The above data is only for your reference. If you have any special request ,pls do not hesitate to contact with us anytime .
Standard function:
Travel function
1
Automatic
running
2
Attendant
running
3
Automatically
adjust door opening time
4
Door
reopen at current floor
5
Arrival
gong
6
Car
call cancel
7
parking
Safety function
8
Light
curtain protection
9
Overload
stop
10
Inspection
operation
11
Fault
self-diagnosis
12
Auto-landing
with fault
13
Door
close repeat
14
Top/bottom
limit and final limit protection
15
Down
running protection
16
Up
running protection
17
Safety
circuit protection
18
Door
interlock protection
19
Main
contactor protection
20
Brake
detecting protection
Human-machine Interface
21
Micro-touch
button
22
Running
state display
23
No
stop floor set
24
Homing
floor set
25
Hoistway
self-learning
Emergency function
26
Emergency
lighting
27
Emergency
electric operation
28
Five-way
intercom
29
Alarm
bell
Energy-saving function
30
fan/light automatic shut-off
Optional Function
Emergency function
1
Auto
Rescue Device(ADR)
Travel function
2
Door
close delay
3
Fire
emergency return
4
Duplex
control
5
Double
door control
Human-machine Interface
6
Car
assistant operation box
7
IC
card control function
Monitor function
8
Traction
machine monitor
