Automobile elevator specification:

Load(kg) Speed(m/s) Mode Rise Height Floor Height Car Floor door Hoistway Generator room with one elevator
GQ VKN TR MAX HE MN AA (W) BB(D) M HH HW HD PP OH AM BM HM
KG m/s m mm mm mm mm mm mm mm mm mm mm mm mm
3000 0.25 TQJ3000/0.25-JXW-VVVF 50/80 3000 2690 6000 2600 2400 4300 6300 1600 4800 4500 7000 2400
5000 0.25 TQJ5000/0.25-JXW-VVVF 50/80 3000 3200 6400 2600 2400 4600 6700 1600 5200 4600 6760 2400


Function:

Standard function:
Travel function 1 Automatic running
2 Attendant running
3 Automatically adjust door opening time
4 Door reopen at current floor
5 Arrival gong
6 Car call cancel
7 parking
Safety function 8 Light curtain protection
9 Overload stop
10 Inspection operation
11 Fault self-diagnosis
12 Auto-landing with fault
13 Door close repeat
14 Top/bottom limit and final limit protection
15 Down running protection
16 Up running protection
17 Safety circuit protection
18 Door interlock protection
19 Main contactor protection
20 Brake detecting protection
Human-machine Interface 21 Micro-touch button
22 Running state display
23 No stop floor set
24 Homing floor set
25 Hoistway self-learning
Emergency function 26 Emergency lighting
27 Emergency electric operation
28 Five-way intercom
29 Alarm bell
Energy-saving function 30 fan/light automatic shut-off
Optional Function
Emergency function 1 Auto Rescue Device(ADR)
Travel function 2 Door close delay
3 Fire emergency return
4 Duplex control
5 Double door control
Human-machine Interface 6 Car assistant operation box
7 IC card control function
Monitor function 8 Traction machine monitor

Note:The above data is only for your reference. If you have any special request ,pls do not hesitate to contact with us anytime .
